Which cable trays need bridging

Cable bridging is typically required for ladder-type, wire mesh, and long-span fiberglass cable trays to support small-diameter or sensitive cables and prevent sagging.

Ladder-

Type Cable Trays

Ladder trays consist of two side rails connected by rungs. When supporting small-diameter multi-conductor control or instrumentation cables, bridging is often necessary to prevent drooping between rungs, especially if the rung spacing is wide (6, 9, or 12 inches) or if the tray carries light cables that do not naturally span the distance without sagging. Bridging ensures proper cable alignment, maintains minimum bend radii, and improves installation neatness.

Wire Mesh Cable Trays

Wire mesh trays, such as those used in Cablofil systems, often require bridging when there are gaps between trays or when the tray spans are long. Bridging provides additional support for cables, particularly in data centers or industrial environments, where maintaining cable integrity and preventing sagging is critical. It also allows installers to bridge gaps without field cutting, keeping installations efficient and safe.

Fiberglass (FRP) Cable TraysFiberglass or FRP trays, including ladder and trough types, may require bridging for control, communication, or instrumentation cables. These cables are often sensitive to mechanical stress, and bridging helps maintain proper spacing and prevents damage from sagging or vibration. Trough or channel FRP trays provide more protection, but bridging may still be used for long runs or when multiple small cables are bundled.

Additional ConsiderationsLong-span trays: Trays with spans exceeding standard support intervals (e.g., 14–20 feet or more) often need bridging to maintain cable support and prevent excessive deflection. Heavy cable loads: While bridging is more common for small or sensitive cables, it can also be used to distribute weight evenly for heavy power cables in ladder trays. Environmental factors: Outdoor or industrial installations with vibration, wind, or thermal expansion may require bridging to maintain cable stability and prevent mechanical stress.

In summary, bridging is essential for ladder trays with wide rung spacing, wire mesh trays with gaps or long spans, and fiberglass trays carrying sensitive or small-diameter cables. Proper bridging ensures cable integrity, maintains bend radii, and supports neat, safe installations.
