Complete Guide to Fiber Optic Socket Panel Dimensions

Fiber optic socket panels typically range from 86 x 86 mm to 120 x 90 x 25 mm, depending on design and port capacity.

Common Sizes

Compact wall-mounted panels: 86 x 86 mm, suitable for single or dual-port FTTH installations, often used indoors for residential or office setups (SC, LC, FC connectors). Standard wall outlet panels: 114 x 70 mm, available in straight, box, or angled designs for indoor fiber termination. Larger indoor panels: 120 x 90 x 25 mm, typically 2-port fiber optic terminal junction boxes, providing extra space for fiber management, bending radius compliance, and protection of fiber cores.

Design Considerations

Port capacity: Panels can range from 1 port up to 24 ports or more, with larger panels accommodating higher density fiber connections. Material and protection: Most panels are made of ABS plastic, offering shock resistance, dustproofing, and sometimes waterproofing for indoor or semi-outdoor use. Installation type: Panels can be wall-mounted, desktop, or integrated into distribution boxes, with dimensions adjusted to allow easy access for splicing, termination, and testing.

Summary

When selecting a fiber optic socket panel, consider the number of ports, connector type, and installation environment. Compact panels (86 x 86 mm) are ideal for minimal space, while larger panels (120 x 90 x 25 mm) provide more room for fiber management and multiple connections. The choice of panel size ensures proper protection, accessibility, and compliance with fiber bending radius requirements.
