Optical Attenuation

Optical attenuation of the 10Gb module

* The 10BASE-E channel shall have attenuation between 5 and 11 dB. If required an attenuator can be added to comply with this specification ** This is the maximum fiber attenuation allowed for standerd single mode fiber at 1550 nm as per IEC 60793-2. There are three wavelength windows for 10G optical module communication applications, namely the 850nm window, 1310nm window, and 1550nm window. Based on the IEEE 10GBASE-LR standard and operating at a 1310nm wavelength, it is widely used in enterprise networks, data centers, and service provider environments where reliable medium-range. SFP-10G-LR Specifications: Optical, Electrical & Link Params provides a comprehensive, engineer-grade breakdown of the specification parameters that define the performance and interoperability of 10GBASE-LR SFP+ optical transceiver modules. These modules are widely used to deliver 10.
