Can a fiber optic cable be connected to a 100Mbps switch

Fiber and communications infrastructure knowledge brief Published 08 Nov 2023

Prepared for preliminary research by the ALFA PRO knowledge desk. Confirm optical interfaces, port or core capacity, electrical input and output, enclosure protection, thermal design and installation limits against current standards and product documentation.

Yes, a 100Mbps switch can be connected to a fiber optic cable using a 100BASE-FX SFP transceiver or a media converter.Using a 100BASE-FX SFP Module

A 100BASE-FX SFP is a 100Mbps Fast Ethernet optical transceiver that allows a switch to transmit data over multimode fiber, typically up to 2 km at 1310nm wavelength . To connect your switch to fiber:

  • Ensure the switch has an SFP port compatible with 100Mbps modules .
  • Insert a 100M Duplex SFP transceiver into the SFP slot; “duplex” means it supports simultaneous send and receive over two fiber strands .
  • Use duplex multimode fiber with LC connectors, matching the SFP module type (single-mode or multimode), .
  • Connect the fiber strands correctly (A to B, B to A) to maintain proper signal flow . This setup allows the switch to communicate over fiber while maintaining its 100Mbps speed.
Using a Media Converter

If your switch does not have an SFP port, a fiber-to-Ethernet media converter can bridge the connection :

  • The converter has an RJ45 port for the switch and a fiber port for the optical cable.
  • It converts electrical Ethernet signals to optical signals and vice versa.
  • This method supports multimode, single-mode, or even single-strand fiber, extending the network beyond the 100-meter copper limitation .
Key Considerations
  • Fiber type: Match the SFP or media converter to the fiber (multimode or single-mode).
  • Distance: 100BASE-FX supports up to 2 km over multimode fiber; longer distances may require single-mode SFPs .
  • Duplex cabling: Always use two strands for full-duplex communication .
  • Compatibility: Verify the SFP or media converter is compatible with your switch model . By using either a 100BASE-FX SFP module or a media converter, a 100Mbps switch can reliably connect to a fiber optic network, providing longer reach, better noise immunity, and stable performance.
