200 Type Cable Tray Support

A 200mm cable tray provides a robust, versatile support system for organizing and securing cables in industrial, commercial, and residential installations.

Overview

A 200mm cable tray is designed to support and route various types of cables, including electrical, data, and networking cables, while maintaining proper ventilation and reducing the risk of overheating or damage. These trays are typically constructed from corrosion-resistant materials such as galvanized steel, powder-coated steel, aluminum, or high-quality PVC, ensuring long-term durability and reliability in different environments.

Load Capacity and Dimensions

Standard 200mm cable trays are often 200mm wide and 60mm deep, with lengths of 2–3 meters per section. They can support up to 48 kg over a 1. 5m span, depending on the material and design.

The trays are engineered to handle heavy loads while maintaining structural integrity, making them suitable for medium-duty to heavy-duty applications.

Installation and Support

Cable trays can be mounted horizontally or vertically on walls, ceilings, floors, or suspended from structures. Support elements such as wall brackets, suspended supports, and center suspensions are used to secure the trays and ensure stability. The trays are compatible with various fittings, including horizontal and vertical bends, T-pieces, crossovers, and reducers, allowing flexible routing and customization.

Cables can be secured using tie-wraps, Velcro straps, or toolless plastic cable rings, ensuring organized and safe cable management. Perforated or mesh designs improve ventilation and heat dissipation, which is critical for high-density cable installations. Compliance and SafetyHigh-quality 200mm cable trays are ISO-certified and comply with standards such as DIN 4102-12: 1998, ISO 14001: 2015, ISO 45001: 2018, and CE certification, ensuring fire resistance and safety in industrial and commercial settings.

They are suitable for indoor and outdoor use, including industrial environments, tunnels, and public buildings.

Advantages

Efficient cable organization and separation of different cable typesCorrosion-resistant and durable for long-term useFlexible installation with horizontal, vertical, or suspended mountingSupports heavy loads while maintaining structural integrityImproved ventilation to prevent overheatingCompatibility with accessories for customized routing and protection Using a 200mm cable tray as a support system ensures a safe, organized, and professional cable management solution that can be tailored to the specific requirements of any project, from industrial sites to residential installations.
