Requirements for optical cable splicing loss

Optical cable splice loss should typically be 0. 3 dB or less, with modern fusion splices often achieving 0. 01–0.

05 dB.

Typical Splice Loss Values

Fusion splices generally exhibit very low loss, typically less than 0. 1 dB, and modern equipment can achieve 0. 01–0.

05 dB per splice. Mechanical splices usually have slightly higher loss, around 0. 2 dB.

Industry standards recommend that permanent splice loss should not exceed 0. 3 dB, and ideally, half of the splices should be below 0. 15 dB.

For contractual or network acceptance testing, some organizations allow a maximum of 0. 35 dB if three re-splicing attempts fail to achieve 0. 30 dB.

Factors Affecting Splice Loss

Fiber alignment: Misalignment of fiber cores is a primary contributor to loss. Even identical fibers can experience attenuation if not perfectly aligned. Fiber geometry mismatch: Differences in core size, core-to-cladding concentricity, numerical aperture, or non-circularity can increase splice loss.

Material differences: Variations in fiber backscatter coefficients can affect measured loss, though not necessarily the actual optical power. Bending and handling: Excessive bending near the splice can introduce additional attenuation.

Testing and Measurement Requirements

Optical Time Domain Reflectometer (OTDR) is commonly used to measure splice loss and analyze fiber spans. Optical Power Meter and Laser Light Source are used to verify continuity and measure power loss at 1310 nm and 1550 nm wavelengths. Calibration: Power meters must be calibrated with a laser light source before testing each span.

Pigtail testing: A 1-km launch reel is recommended to accurately measure connector and adjacent splice loss. Acceptance criteria: Any splice exceeding 0. 30 dB must be re-spliced; after three attempts, the maximum allowable loss is 0.

35 dB.

Best Practices

Use core-alignment fusion splicers for lower-loss splices. Ensure trained and qualified personnel perform splicing and testing. Conduct unidirectional or bidirectional testing depending on network requirements.

Maintain clean and defect-free launch cords and adapters during OTDR testing to ensure accurate measurements. By adhering to these requirements and best practices, optical cable splices can achieve minimal attenuation, ensuring reliable signal transmission and compliance with industry standards.
