A terminal bridge is an accessory used to electrically connect multiple terminal blocks, allowing current to pass between them efficiently.

Overview

A terminal bridge is a small conductive component that links two or more terminal blocks in a control panel or electrical system. It enables simultaneous electrical connection across multiple terminals without the need for separate wiring, simplifying installation and reducing clutter in terminal strips.

Function and Benefits

Electrical Continuity: Bridges allow current to flow between connected terminals, creating a common electrical point for multiple circuits. Efficiency: Using bridges reduces the number of individual wires needed, speeding up assembly and maintenance. Flexibility: Many terminal block systems, such as those from Phoenix Contact, feature standardized bridging options that can be combined freely using a double function shaft.

Cost Reduction: Fewer wires and components lower logistics and storage costs while maintaining reliable connections. Types and InstallationSingle-Level Bridges: Connect terminals in a single row.

Multi-

Level Bridges: Connect terminals across multiple rows or levels for more complex circuits. DIN-Rail Mounting: Most terminal blocks and bridges are designed for DIN-rail mounting, allowing modular and organized installation.

Tool-

Free Options: Some systems, like Push-X terminal blocks, allow bridges to be installed without tools, even for conductors with ferrules.

Applications

Terminal bridges are widely used in industrial control panels, automation systems, and electrical distribution boards. They are essential for creating common voltage points, grounding connections, or distributing signals efficiently across multiple devices.

Where to Obtain

Terminal bridges can be purchased from industrial suppliers such as Graybar, McMaster-Carr, and Phoenix Contact, which offer a variety of sizes, materials, and configurations suitable for different terminal block systems. Using terminal bridges ensures reliable, organized, and cost-effective wiring in complex electrical systems.
