Huawei Core Switch Layer 2 Interface

Fiber and communications infrastructure knowledge brief Published 17 Nov 2023

Prepared for preliminary research by the ALFA PRO knowledge desk. Confirm optical interfaces, port or core capacity, electrical input and output, enclosure protection, thermal design and installation limits against current standards and product documentation.

Huawei core switch Layer 2 interfaces forward traffic based on MAC addresses, support VLANs, and can be configured as access or trunk ports to interconnect with routers or other switches.Layer 2 Interface Basics

A Layer 2 interface on a Huawei switch operates at the data link layer of the OSI model, forwarding Ethernet frames based on MAC addresses. Each port belongs to a separate collision domain, and the switch maintains a MAC address table to map MAC addresses to ports. When a frame arrives, the switch checks the destination MAC address and forwards it to the appropriate port. Broadcast frames are sent to all ports except the source port, and MAC table entries are aged out if not updated within a set time .

VLAN Configuration

Layer 2 interfaces are typically assigned to VLANs to segment network traffic. On Huawei switches, you can configure a port as:

  • Access port: Assigned to a single VLAN, used for end devices.
  • Trunk port: Carries multiple VLANs, used for inter-switch links or router connections. Example configuration for access ports:

vlan batch 2 3interface g0/0/2[Huawei-GigabitEthernet0/0/2] port link-type access[Huawei-GigabitEthernet0/0/2] port default vlan 2[Huawei-GigabitEthernet0/0/2] quit

This sets GigabitEthernet0/0/2 as an access port in VLAN 2 .

Interfacing with Routers

When connecting a Layer 2 switch to a router, there are two common methods:

  1. Router with Layer 3 interface: Configure multiple subinterfaces on the router for each VLAN (single-arm routing). The switch ports remain Layer 2 access or trunk ports.
  2. Router with Layer 2 interface: The router uses a VLANIF interface to assign an IP address for the VLAN. The switch ports are configured as access ports in the corresponding VLAN, allowing Layer 2 communication .
Layer 2 Connections in Enterprise Networks

Huawei enterprise switches can create Layer 2 connections to extend VLANs across remote sites using VXLAN tunnels. Each connection links a local and remote Layer 2 subnet, with unique tunnel VNIs and reserved IP addresses for active and standby interfaces. This allows Layer 2 communication between on-premises data centers and cloud-based enterprise switches .

Core Switch Considerations

On Huawei core switches, Layer 2 interfaces are often used to interconnect with BRAS devices, firewalls, or aggregation switches. VLANs are created on the core switch, and interfaces are added to these VLANs. For Layer 2 interfaces that require IP routing, a VLANIF interface can be bound to a VPN instance to isolate traffic and configure OSPF or other Layer 3 protocols .

Summary
  • Layer 2 interfaces forward traffic based on MAC addresses and maintain a MAC table.
  • Ports can be configured as access or trunk depending on network design.
  • VLANs segment traffic, and VLANIF interfaces provide Layer 3 IP connectivity if needed.
  • Layer 2 connections can extend VLANs across sites using VXLAN tunnels.
  • Core switch Layer 2 interfaces often interconnect with routers, firewalls, or aggregation switches, supporting both Layer 2 forwarding and optional Layer 3 routing through VLANIF interfaces.
